| Model |
Contex HD Apeiron/42 |
| Suitable for (among many others) |
Fine art, artwork, posters and prints, interior design materials, textiles, delicate documents |
| Media loading |
Contact-free face up scanning |
| Scan size (W×L) |
Maximum: 42×60 in (1067×1524 mm). Minimum: 1×1 in (24.5×24.5 mm). |
| Media size (W×L) |
Maximum: 43.8×64 in (1113×1625 mm). Minimum: Media smaller than the min. scan size can be cropped in the software. |
| Maximum focus plane above table |
5.1 in (130 mm). Maximum clearance height: 10 in (254 mm) |
| Maximum focus depth |
+/- 10 mm |
| Maximum weight on scanner table |
Up to 44 lbs (20 kg), evenly distributed |
| Scanning speed (inches/second) |
300 dpi, 24-bit color |
600 dpi, 24-bit color |
1200 dpi, 24-bit color |
| Plane surface |
6 ips |
1.5 ips |
0.12 ips |
| Uneven surface |
5.5 ips |
1.38 ips |
0.28 ips |
| 3D surface effect |
2.75 ips |
0.69 ips |
0.11 ips |
| Optical resolution |
1200 dpi (maximum 9600 dpi, interpolated) |
| Total number of pixels |
256,320 pixels |
| Accuracy |
0.1% +/- 1 pixel |
| Data capture color depth |
48-bit color/16-bit monochrome |
| Image types |
24-bit color, Indexed color, 8-bit grayscale, 1-bit black/white, Fine lines and fills, Fixed threshold, Dither |
| Color spaces |
sRGB, Adobe RGB, Device RGB |
| Color profile |
ICC color management powered by X-Rite® |
| Cameras |
6 CCD cameras with Fujifilm lenses and quad-linear Toshiba color CCDs (RGB and grey) |
| Height adjustment and focus detection |
Yes. By lasers in the scan module. (Patent pending) |
| Light sources |
2 LED lamps with dual LED strips, mounted in elliptical reflectors. LED spectrums: 2700K, 5000K, 6500K |
| Light exposure |
No unnecessary light exposure. Scanning light is narrowly projected to the scan line only. |
| Lamp specifications |
No UV/IR radiation. No warm up time. Lifetime = scanner lifetime. |
| Lamp angles |
Four options for different angles of lighting |
| 3D surface effect |
Yes. Post-scanning option in the software to slide for desired 3D surface effect |
| Table conveyance system |
Precision timing belt transmission with triple-point direction control system |
| Movement controls via software |
Scan module: Up/down. Table: Forward/reverse |
| Red emergency stop button |
Yes |
Features
- Our contact-free art scanner HD Apeiron/42 uses unparalleled technology to accurately digitize media. With the market’s most realistic image quality, full light control and a unique ability to emphasize details, the scanner is ideal for fine art, fragile originals and more.
This is especially suited for museums, copy shops, material manufacturers, and others, who now have a powerful new way to boost the quality of detailed and delicate originals with unprecedented accuracy.
- The clearance height of 10 inches (254 mm) and an optimal focus plane of up to 5.1 inches (130 mm) enables scanning of thicker media, such as framed artwork.
- Six cameras with Fujifilm lenses and quad-linear Toshiba color CCDs capture all details in up to 1200 dpi optical resolution.
- The lamps in HD Apeiron/42 recreate the natural daylight spectrum using cutting-edge LEDs with TRI-RTM technology. This, plus the clever design of LED strips mounted in elliptical reflectors, results in correct and uniform colors – and no distance fading.
- Creating expressive shadows and highlights to add lifelike 3D surface sensations is also easy. HD Apeiron/42 offers four different lamp positions. The museum-correct light with no UV/IR radiation conserves the art.
- HD Apeiron/42 is the fastest contact-free large format scanner on the market. A flexible solution; it improves workflows while ensuring superior quality. The hardware is designed to support correct ergonomics for the operator; this includes an adjustable arm with a large 22” touchscreen.
- A customized and easy-to-operate version of our Nextimage award-winning software, Nextimage Apeiron, is included. All required parameters are readily accessible on the touchscreen rather than hidden behind tabs or dropdown menus. A variety of post-scanning options also allow the user to adjust parameters and effects, if desired.
- HD Apeiron/42 is a flexible product that improves existing workflows when digitizing original artwork.
No accessories can be found for this product. Please reach out to us for further information.
No parts can be found for this product. Please reach out to us for further information.
- Contex HD Apeiron/42
- Power cable
- 22” touchscreen (VESA mount 75×75 mm and 100×100 mm) with adjustable position for optimal ergonomics
- Included software: Nextimage Apeiron (English, German, French, Italian, Spanish, Portuguese, Polish, Russian, Korean, Chinese (simplified), Japanese)
- User documentation
Standard Warranty: 24 months parts only.
Extended Spare Parts Warranty
| Description |
Mfg# |
Price |
Cart |
1 Year Warranty Extension for Spare Parts
Extends spare parts warranty to 3 years. Must register scanner within 3 months of delivery.
|
CS2861A101
|
$3,370.00 |
Add |
3 Years Warranty Extension for Spare Parts
Extends spare parts warranty to 5 years. Must register scanner within 3 months of delivery.
|
CS2861A102
|
$8,485.00 |
Add |
1 Year Warranty Extension for Spare Parts - POST (within factory warranty)
Extends spare parts warranty to 3 years. Must register scanner within factory warranty.
|
CS2861A103
|
$5,560.00 |
Add |
3 Years Warranty Extension for Spare Parts - POST (within factory warranty)
Extends spare parts warranty to 5 years. Must register scanner within factory warranty.
|
CS2861A104
|
$11,920.00 |
Add |
1 Year Warranty Extension for Spare Parts - POST-EX (within extended warranty)
Extends spare parts warranty from 3 to 4 years. Or from 4 to 5 years. Must register scanner while in a current extended warranty.
|
CS2861A105
|
$6,750.00 |
Add |
|
|
