Contex HD Ultra X 4290

Contex HD Ultra X 4290
42" Wide Format Scanner


List Price: $10,995.00
Call or Email for Pricing
.

Call or Email for quantity discounts

The size-flexibility, our Nextimage software and the unprecedented scan width gives you the flexibility to be smart and create a more efficient workflow.

With the Contex HD Ultra X 4290 we have tried to reduce the total cost of ownership because we know it matters to you. We´ve used optimized LED lights, so you don't have to think about replacing the lamps. Nor do you have to worry about maintenance to the same extent as other scanners. Best of all we´ve made the glass super-resistant to scratches and created a paper handling design that will prolong the life of your consumables.

This all adds up to the most efficient and flexible large format scanner on the market.


The widest and fastest CCD scanner

There are many obvious reasons to want the Contex HD Ultra X 4290. It is 42 inches wide and it is ultra-fast with the ability to scan in RGB color in 200 dpi at up to 17.8 ips.

The Contex HD Ultra X is the fastest scanner we've ever made. With a top speed of 17.8 ips, you can increase your workflow tempo significantly. You can also switch between three different speed levels directly on the scanner's intuitive touch panel. If speed doesn't impress you, look at the width.


Best-in-class scan quality

With the Contex HD Ultra X 4290 you get the highest quality scans the market has to offer. Using the newest CCD technology and Contex's specially designed Fujifilm lenses, you get nearperfect color match and crystal clear scans. No matter if your originals are thick, thin, wide or creased. Furthermore, it will always be in focus with a depth of focus up to 7 mm (0.28 inches).

Time is money

That is why we're sure you will enjoy our new timesaving features. Instant-ON makes sure you don't need to warm up your scanner before using it. You feed your original into the scanner, and it turns on. As a bonus, it is good for the environment and reduces your electricity bill. The Contex HD Ultra X 4290 also has true size detection, which instantly detects your originals width and saves valuable time.







Order Today!

Contex HD Ultra X 4290  Wide Format Scanner


Contex HD Ultra X 4290  Scanner  Contex HD Ultra X 4290  Scanner   Contex HD Ultra X 4290  Scanner


Canon DR-6030C Scanner Brochure

Other Contex Scanners


42-inch wide design captures
    oversized documents easily

Advanced 48-bit CCD technology with the very latest
    in (LEDs).

Gigabit Ethernet xDTR2.5 Optimized for up to 100 MB
   per second. Scan-to-Net function for scanner sharing
   across a network, and sending files to remote PCs

Combining automatic thickness adjustment control
   (ATAC), all wheel drive (AWD) paper feed tracking
   system

Ultra fast USB 3.0 SuperSpeed xDTR3 delivering 3
   times the bandwidth of USB2



















CLICK HERE FOR DRIVERS

  Energy Star Certified Fuji Film Lenses RoHS RoHS

  • Specifications
  • Features
  • Accessories
  • Parts
  • In the box
  • Warranty
Model Contex HD Ultra X 4290
Maximum Scan Width 42 inch (1067 mm)
Resolution 1200 dpi
Enhanced resolution 9,600 dpi
Scanning speed (inch/sec.) 17.8"/s in 200dpi Grayscale/Monochrome, 8.9"/s in 200 dpi RGB Color
Productivity (documents/hour):
Batch scanning for 60 minutes. Includes paper load and eject time. Measured in completed scans.

Arch E-size, RGB Color, 200dpi portrait load: 866 pages
Arch E-size, RGB Color, 200dpi landscape load: 1054 pages

Scan accuracy 0.1% +- 1 pixel
Maximum thickness 0.06-inch (15 mm)
Data Capture (color/mono)
48-bit color / 16-bit grey scale
Color space Adobe RGB, Device RGB, RAW RGB, sRGB
Interface USB 3.0 with xDTR3, Gigabit Ethernet with xDTR2.5
Weight/dimension/power
49 kg (108 lbs) / LxWxH: 1360mm (53.5'') x 475mm (18.7'') x 200mm (7.9''), 100 - 240V, 60/50Hz, 80W
Device Drivers 64-bit Windows 10, 8, Windows 7
System software WIDEsystem (driver): Nextimage 5 iOS app (portable device) Android tablet/phone OS also
TWAIN 64-bit TWAIN application driver included for use with EDM and other imaging software
Host platforms 64-bit Windows 10, 8, Windows 7
Certifications RoHS, cUL, CE, Customs Union, CCC, VCCI, KC, Ukr, ENERGY STAR certified



Contex Large Format Printers Cert Banner

Contex True Size Detection

HD Ultra X finds the paper width as it scans. No wasted time. No shoe shine just instant width detection. No more backwards and forwards movement of document while feeding it into the scanner. Just load and scan.

Static Free Touchless Glass System

Enjoy virtually scratch free glass plates thanks to the new design of the white background pressure plate in the HD Ultra X. The pressure point is offset of the scanning line helping the glass stay free from scratches. The Minimal-friction, floating transport design of glass plate with new quick-release magnetic scan glass system, makes replacement or cleaning of glass plate easier and faster than ever.

OTAC

Optimized Thickness Adjustment Control. With one press of a lever, raise and lower the OTAC to suit required media thickness. It is very fast.

FlexDoc

Combining automatic thickness adjustment control (ATAC), all wheel drive (AWD), automatic contour correction and a new paper pressure adjustment, Flex- Doc enables you to scan anything from newspaper-thin documents to posters on foam boards, gator boards and other bulky documents up to 0.6" thick.

FlexFeed

With removable, no-rewind paper return guides, right-side loading, a funnelshaped feeder, and a convenient new exit tray, FlexFeed takes the hassle out of scanning any document.

SnapSize

SnapSize makes it faster and easier to switch between different-sized documents by eliminating the need for manual software adjustments. Precision optical paper sensors register your document size and adjust the required settings automatically.

SmartShare

This allows all users in a workgroup to operate the scanner from their own computer via Ethernet.

USB 3.0 SuperSpeed xDTR3

We have adapted our xDTR technology to work with the USB 3.0 SuperSpeed protocol increasing its performance dramatically. It has the fastest data transfer rate of any scanner on the market.

Gigabit Ethernet xDTR2.5

Optimized for up to 100 MB per second. Up to 60% faster transfer rate than with xDTR2 thanks to new improved electronics.

Gbit throttling buffer control

1GB buffer eliminates scanner pausing. Maintain your scan speeds and meet those deadlines

Contex Perfect Light

Contex Perfect Light in the HD Ultra X comes from engineers carefully selecting the very latest in light-emitting diode technology (LEDs) and combining this with specially developed diffusion filters.

AccuColor

To get the best results, your scanner and software should work with full 48-bit data. Where other scanners ignore some of this data, the HD Ultra is the world's wide format scanner with true 48-bit color capture.

CCD

Contex uses All-Digital cameras with advanced point-of-origin capture and onboard digital conversion ensuring minimum noise and an extended dynamic range. The unique four-linear CCD technology, with a special panchromatic line, ensures that no colors are lost when scanning monochrome. Quality colormatched fluorescent lamps ensure the market's highest standards for color correctness.

ALE

Accuracy Lens Enhancement (ALE) technology that electronically maintains 0.1% +- pixel precision across any two points of the scan line thus exceeding even the most rigid requirements in the industry today. Contex delivers a very high grade of precision stability in the scanned image.




High-quality lenses

Contex CCD scanners use premium Fujifilm lenses to bring you high-resolution images in the best quality available on the market today.

Using the highest quality LED lights on the market and the latest Contex CCD technology, our research shows that the optimal color reproduction is already achieved at 4000 Kelvin.

Adobe RGB

The preferred choice for color professionals who need the maximum number of colors from the scanning process and is the best choice for high-quality printing. sRGB color space is best for display viewing and general printing.

ICC profiles work to ensure accurate color reproduction on your chosen device (the device must be able to support selected color space).

Fujifilm lenses

Using lenses specially selected to support the size and resolutions used in the HD Ultra X 6000 scanner. This avoids the uneven sharpness and chromatic distortions that can occur when using cheaper, smaller lenses.

Contex CCD's are Quadlinear which means we have a red, green, blue and black channel on our CCD's. This gives us the truest grayscale and monochrome. Our closest competitor uses Tri linear CCD's which mean they only have red, green and blue and must get their monochrome and grayscale from the green channel which does not reproduce the best mono or grayscale.

Contex Natural Light

Fuji Film Lenses

Only a high Color Rendering Index ensures accurate colors. The CRI (Color Rendering Index) is an indicator of how close artificial color reproduction is compared to natural light. Natural light has a CRI of 100. A Contex HD Ultra X scanner uses a light source with a high CRI CRI (more than 90). Compensated by the perfect light system, this is by far the highest CRI amongst CCD large format scanners.

X-Rite ICC profiles

X-Rite is the global leader in color science and technology. The Company, which now includes color industry leader Pantone, Inc., develops, manufactures, markets and supports innovative color solutions through measurement systems, software, color standards and services. X-Rite's expertise in inspiring, selecting, measuring, formulating, communicating and matching color helps users get color right the first time, and every time, which translates to better quality and reduced costs. X-Rite serves a range of industries, including scanning, printing, packaging, photography, graphic design, video, automotive, paints, plastics, textiles, dental and medical.


Contex HD Ultra X 4290 Features



Software
Description Mfg# Price Cart
Nextimage SCAN+ARCHIVE
Contex Full-featured Productivity Scanning software
9691A601 $650.00 Add
Nextimage REPRO license
Contex Touch-compatible Full-featured Productivity Scan + Copy software
9691A602 $1,295.00 Add
Nextimage MFP to REPRO Upgrade
Upgrade from Nextimage MFP (requires installed MFP license)
9691A089 $1,425.00 Add
Nextimage SCAN+ARCHIVE to REPRO
Upgrade from Nextimage Scan + Archive to Repro (Requires installed Nextimage Scan+ Archive license)
9691A603 $1,050.00 Add

HD Accessories
Description Mfg# Price Cart
Document carrier sheet
36 x 48 inch carrier sheet portrait
6399D133 $210.00 Add
USB2.0 Cable, A/B with Ferrite
6799D172R01 $63.00 Add
USB2.0 Cable, A/B, 3m
USB2.0 Cable, Shielded, A/B, 3m
0090B068R01 $51.00 Add
Consumables
Description Mfg# Price Cart
White Background Plate, X42, packed
2867G148 $173.31 Add
Glass Plate, X42, packed
2867G149 $713.81 Add
Calibration Sheet, X42, packed
2867G150 $361.31 Add

Other Parts
Description Mfg# Price Cart
Filter kit, 92x92 (for 0080C032)
Contex Filter kit, 92x92
0080C031R01 $55.52 Add
Contex Inlet
0007S046R01 $103.11 Add
DC Gear Motor, 12V, 392:1, ø27mm
Camera height adjustment motor - HD Ultra scanner
6798G008 $185.06 Add
LHS End Cover, Rx67G
Contex LHS End Cover, Rx67G
6798G012 $203.57 Add
Castors (4 pcs.)
For IQ, SD and HD Ultra 42" model stands
0601A005R01 $132.19 Add
ATAC Closed Sensors
Contex ATAC Closed Sensors
6798G002 $155.98 Add
PSU, 24V/200W ATM200T
2867G107 $557.83 Add
SUX Variant A
2867G108 $4,631.85 Add
Camera Module RB67G
2867G109 $1,390.61 Add
IBD Variant A
2867G116 $515.53 Add
RFI-Fifter
0077E036R01 $121.61 Add
Stepper Motor STP-590D1 + Pulley + Damper
2867G117 $787.84 Add
Cooling Fan, 92x92x25
2867G118 $280.24 Add
Tacho Sensor
2867G110 $179.78 Add
Paper/Lid Sensor (1 pcs.)
0075A160R01 $116.33 Add
Shaft with Feed-Rollers 60" (2 pcs. )
2867G119 $1,628.55 Add
Drive Belt, S2. 1167M 500mm
2867G122 $174.49 Add
Idle Rollers HDU X60 (2 pcs.)
2867G131 $914.74 Add
Cover Assy. RHS(incl Operators Panel)
2867G120 $713.81 Add
Gas Spring, Guideplate, 2 pcs.
2867G111 $142.76 Add
USB3.0 + 1Gbit Cable, 0.4m, Panel Mount
2867G121 $259.09 Add
Feed Table Cover RB67G
2867G123 $1,073.36 Add
Latch Kit tor HDU ATAC/OTAC
2867G130 $211.50 Add
FFC Cable Kit
2867G137 $311.96 Add
Roller Cover, Front
2867G138 $417.71 Add
Roller Cover, Rear
2867G139 $417.71 Add
OTAC Complete Assv
2867G140 $4,507.59 Add
Springs for ATAC, RA67G (2 pcs)
2867G102 $42.30 Add
  • Contex HD Ultra X 4290
  • Power cable
  • 64-bit TWAIN application driver included for use with EDM and other imaging software
  • User documentation
  • Scanner Maintenance Software
  • Maintenance Sheet
Standard Warranty: 24 months parts only.
Extended Spare Parts Warranty
Description Mfg# Price Cart
1 Year Warranty Extension for Spare Parts
Extends spare parts warranty to 3 years. Must register scanner within 3 months of delivery.
2898A124 $554.00 Add
3 Years Warranty Extension for Spare Parts
Extends spare parts warranty to 5 years. Must register scanner within 3 months of delivery.
2898A125 $995.00 Add
1 Year Warranty Extension for Spare Parts - POST (within factory warranty)
Extends spare parts warranty to 3 years. Must register scanner within factory warranty.
2898A141 $782.00 Add
3 Years Warranty Extension for Spare Parts - POST (within factory warranty)
Extends spare parts warranty to 5 years. Must register scanner within factory warranty.
2898A142 $1,495.00 Add

On-Site Warranty
Description Mfg# Price Cart
Onsite Service - 2 years - HD
Optional 2 Years On-site Warranty for HD scanners -pricing available at time of purchase with a new HD scanner.
2898A118HD $995.00 Add
Onsite Service - 3 years - SD/IQ44 or HD
3 Years On-site Warranty Available only at time of purchase.
2898A119 $2,020.00 Add
Onsite Service - 4 years - SD36/IQ44 or HD
4 Years On-site Warranty Available only at time of purchase.
2898A120 $2,765.00 Add
Onsite Service - 5 years - SD36/IQ44 or HD
5 Years On-site Warranty Available only at time of purchase.
2898A121 $3,610.00 Add
Onsite Extention - 1 year - SD36/IQ44 or HD (in warranty)
1 Year On-site Warranty Extension -for products currently under warranty
2898A122 $1,295.00 Add
Onsite Extention - 1 year - (XD24/IQ24, SD36/IQ44 and HD - (post warranty)
1 Year On-site Warranty -for products NOT currently under warranty. Not available on past models.
2898A123 $1,395.00 Add
